Introduction
Feature
Diffused-Silicon oil filled core
All kinds of structure to satisfy different users
Easy to use with submersible measuring
Multiple pressure range and signal output
Non-polar 2 wire system current output
Can be used in lightning protection products
Reinforcing rib of liquid cable
Intrinsically safe explosion proof, Isolation explosion proof, CE
Application
Deep well level measuringHydrologic measurement for river, lake, sea
Sewage treatment
Cloudy level measuring
Fluid reservoir level measuring
Water-saving irrigation
Circulating liquid consumption monitoring
Diversion works
Parameter
Spec. | Numerical value |
Pressure range | 0~1……500mH2O 9.8KPa…4900KPa 0.09bar…49bar 0.09atm…48atm 1.4psi… 711psi 2.8inchHg…1400inchHg |
Overload pressure | 1.5 times nominal value |
Rupture pressure | 3 times nominal value |
Accuracy | ±0.25%F.S,±0.5%F.S |
Stability | Typical value 0.25%F.S, Max. value:0.4%F.S |
Operating temperature | -40°C~85°C (or -40°C~125°C) |
Compensation temperature | -10°C~70°C |
Medium | All Caustic Medium Compatible with 1Cr18Ni9Ti |
Electrical performance | 2 line | 3 line | 4 line |
Output signal | 4~20mA | 0~20mA | 0~5V | 0.5~4.5V | 0~20mA |
| | 0~10Vdc | 1~5V | 0.5~3V | 0~5/10Vdc |
Power supply | 10~30Vdc | 11~30Vdc | 8~24Vdc | 5V Ratio | 8/11~30Vdc |
Load resistance | (U-10)/0.02(Ω) | Current:(U-12)/0.02(Ω); voltage :>20KΩ |
Insulation | >100MΩ @50V |
Electrical Connections | 500V@1 second |
Electrical connection | waterproof fixed cable + Two rectangle circle+ Sealing Rings+ seal
gum+ Pure glue protection grade : IP68 |
Electromagnetic compatibility | electromagnetic radiation EN50081-1/-2, electromagnetic
susceptibility: EN50082-2 |
Response time | 10ms |
Certificate | Intrinsically safe mode E, explosion proof type D, CE |
EMI/EMC | EMI: EN50081-1/-2; EMC: EN50082-2 |
Company Information
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety
explosion-proof and isolated safety explosion-proof, etc. which
assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow
measuring instruments and related products for 10 years. We have
experienced technical and management personnel, through the efforts
of our entire staff, we have become a professional measuring
instrument manufacturer and solution provider. And we are
continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain,
Australia, Chile and 20 other countries and regions, and received
many favorable feedbacks. Our overseas distributers are also
increasing. We regards “reasonable prices, efficient production
time and good after-sales service” as our tenet, and hope to
cooperate with more customers for mutual development.
FAQ
1. Q: What information need to be provided to choose the suitable model?
A: Please provide us: application field, pipe size , pipe material, medium( liquid type),
temperature, installation method, so we can choose model and quote for you quickly.
2.Q: May I put my own logo on the product?
A: Sure. Logo can be printed on the housing, and company name can
be engraved on the nameplate.
3.Q: How about the quality control?
A: All products will be tested for 3 times before packed.
4.Q: May I release trial order, 1 pc for example?
A: Certainly, trial order is acceptable. In general, we have common
models in stock. Sample will be sent within 1 week, after payment
is received.
5.Q: Could you design according to my requirements?
A: Of course, our team will design for you.
