KUS650 Ultrasonic Level Sensor
1. Product overview
KUS650 series intelligent wireless digital wireless liquid
level/level sensor is an intelligent digital display product with
high precision and high stability introduced by our company.
Suitable for real-time measurement and display of liquid
level/material level. This product adopts special wide temperature
liquid crystal display, high stability sensor, and is carefully
manufactured through precise digital temperature compensation and
nonlinear correction technology to ensure the high precision and
high stability of liquid level/level measurement. The built-in
wireless module uses the network to provide users with wireless
long-distance and low-power data transmission, and sends all the
status data of the sensor to the cloud background management server
in real time to realize alarm linkage and data statistical analysis
with the smart cloud platform.
2. Product Features
◆Power: Two DC3.6V primary lithium sub-battery
◆Wireless transmit power: <23 dBm
◆Receive sensitivity: <-135 dBm
◆Theoretical bandwidth: 200Kbs
◆Support wireless transmission of alarm status to server,
configurable server address and port
◆Using precise digital temperature compensation and nonlinear
correction technology, wide temperature range and full scale
precision compensation;
◆Multiple data type indication (percentage, output current
display);
◆Special wide temperature LCD display (-30℃～80℃);
◆Provide a variety of power supply methods at the same time;
◆Vertical installation or axial installation, providing a variety
of liquid level/level interfaces and interface materials;
◆ LCD with parameterization and three setting buttons.
◆According to user needs and site conditions, the collection
frequency and collection time interval can be set.
◆Battery power monitoring, when the power is insufficient, the
meter screen will flash and report to the centralized management
platform at the same time.
◆Water pressure/water level alarm threshold can be set and modified
according to actual needs.
◆Water pressure/water level alarm threshold automatically alarms.
3.Introduction
This sensor provides very short to long-range detection and
ranging, in a compact, robust PVC housing,
designed to meet IP65.
4.Technical parameters
Enter |
Measured variable Liquid | level, material level |
Maximum measuremen trange | 1.2-30m (can be customized according to demand) |
Output |
Comprehensive accuracy | ±0.15%FS/ 0.15℃ |
Temperature compensation | -10℃～70℃ |
Vibration effects | < ± 0.05%/g, 500Hz in all directions (according to IEC 68-2-64) |
Rated conditions environmental conditions |
Ambient temperature | -25～+85℃ |
Storage temperature | -40～+85℃ |
Protection class | IP68 , according to EN 60529 |
Electromagnetic Compatibility | EN 61326/A2 Annex A (2001) |
Display and control |
Display | SFTN liquid crystal, white backlight, 5-digit display. |
Limit | value Free setting |
Parameter | setting Use 3 buttons |
Unit | The unit is mm, and the default unit is m. |
Weight | about 1.35kg |
Materials of non-wetted parts |
Joint | 1NPT, stainless steel, length 20mm (material and joint
specifications can be customized according to customer
requirements). |
Electrical connection | Make waterproof connector, air vent cable entry according to EN
175301-803A standard |
Measurement period | ≤ 100ms |
Selection Tips: For special requirements, please contact our
company and indicate it in the order.
1. If you need to calibrate the meter, please contact our company.
Non-professionals are not allowed to calibrate the meter.
2. When calibrating the meter, please turn on the meter first, and
calibrate it after 1 hour of constant temperature.
