4-20mA High Precision Ultrasonic Level Meter With Two-wire Output

Ask Lasest Price
Brand Name :	KACISE
Model Number :	KUM-100
Certification :	CE
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000 Piece/Pieces per Week negotiable
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

4-20mA High Precision Ultrasonic Level Meter With Two-wire Output

Product Description

The 4 - 20mA high precision ultrasonic level meter with two - wire output is an advanced and reliable instrument. It utilizes ultrasonic technology to accurately measure the level of various substances. With its two - wire output design, it simplifies installation and wiring, making it convenient for integration into different industrial control systems. The 4 - 20mA signal output enables seamless communication with other devices and provides highly precise level data. It is suitable for a wide range of applications, such as liquid storage tanks, chemical processing plants, and water treatment facilities, ensuring efficient and accurate level monitoring and control.
Feature

LCD display
Solid level/liquid level mode selection
Can arbitrarily set the starting point and end point of the output range
With 4G/LoRa wireless communication (optional)
With restore setting function, support to restore factory settings
With digital filtering, dynamic echo recognition*Digital sensor, RS-485 output, support MODBUS
No reagents, no pollution, more economical and environmentally friendly
Automatically compensates for pH and temperature in water

Parameter

Range	0-10m
Accuracy	±0.5%F.S
Display	LCD
Power supply	DC12-28V
Electrical interface	M16*1.5
Protection	IP65
Blind zone	0.4m
Resolution	1mm
Keys	Three patch buttons
Power consumption	<0.6W
Thread	G2
Working environment	temperature & pressure
Output	2-wire 4-20mA, HART(optional)

Working Principle & Wiring

Product Dimension

Cases

Production Flow

Product packaging

Company Profile

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety
explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.

Our Services

* Your inquiry will be replied in 24hours.
* Well-trained and experienced staffs to answer all your enquires in fluent English.
* OEM&ODM, we can help you to design and your request will be put into product.
* Distributorship are offered for your unique design and some our current models.
* Protection of your sales area, ideas of design and all your private information.
* Discounts are offered based on order quantities.
